Product Specs
- FRAME MATERIAL: Chromoly Front End
- WHEEL SIZE: 20"
- TOP TUBE LENGTH: 20.75"
- CHAIN STAY LENGTH: 12.6"
- HEADTUBE ANGLE: 75.5°
- SEAT TUBE ANGLE: 71°
- FORKS: Chromoly Steerer Tube and Hi-Ten Legs
- BARS:
- MATERIAL: Hi-Ten
- TYPE: 4-Piece
- RISE: 9" Rise
- WIDTH: 29" Width - STEM: Alloy Top Load
- HEADSET: INTEGRATED
- BRAKE MOUNTS: Removable
- BRAKES: U-BRAKE
- FRONT HUB: Sealed
- FRONT RIM: Single Wall
- REAR HUB: Sealed Cassette
- REAR RIM: Single Wall
- TYRES: 2.4"
- SPROCKET: 25t
- CRANKS:
- MATERIAL: Chromoly
- TYPE: 3-Piece
- ARM LENGTH: 165mm - BB: 19mm Mid
- PEDALS: Plastic
- SEAT: Combo Seat/Post
- GEARING: 25/9
- WEIGHT: 27.69lbs (13kg)
Product Highlights
- Great for riders who are between 5ft and 6ft tall (150cm - 180cm)
- Designed to excel at Street riding thanks to responsive geometry but will feel at home in any riding environment
- Strong Hi-Ten steel construction
- Great spec for a BMX in this price bracket
- High-quality aftermarket tires
NEED SOME HELP CHOOSING A BMX BIKE?
We have compiled a complete BMX buyers guide to help you through the process! Keep reading to find out more about your perfect BMX bike. Here at SourceBMX we are all riders, so we can offer advice that only 100% rider-owned BMX shops can - just ask.
Click here to view all BMX Bikes
BMX BIKE SIZE GUIDE
BMX bikes are measured in two ways: the size of the wheel (20” is the standard BMX wheel size), and the length of the frame which is gauged by the top tube measurement. We have also simplified for you into XS, Small, Medium, etc.Here is a guide to what size you should be looking for - note that there is some overlap in sizes, as personal preference also comes into the equation!
Rider Height (in) | Rider Height (cm ) | Wheel Size (in) | Top Tube Length (in) |
---|---|---|---|
2FT - 3FT | 60 - 90cm | 12" | 11.5" - 13" |
2'8" - 3'4" | 80 - 100 cm | 14" | 2.8" - 15" |
3FT - 3'8" | 90 - 110cm | 16" | 14.5" - 17" |
3'6" - 4'6" | 105 - 135cm | 18" | 17" - 18.5" |
4'6" - 5'1" (XS) |
135 - 155cm | 20" | 18" - 20" |
4'10" - 5'4" | 147 - 162cm | 20" | 20" - 20.25" (XS - S) |
5'2"- 5'8" | 157 - 173cm | 20" | 20" - 20.5" (S - M) |
5'6" - 6FT | 165 - 185cm | 20" | 20.25" - 21" (M - L) |
6FT + | 180cm + | 20" | 20.75" + (L - XL) |
